LC FBG Reflector Pigtail Hom
LC FBG Reflector Pigtail Hom 1.Optical fiber ntau reflector yog ib qho khoom siv kho qhov muag uas tsuas tso cai rau qee qhov wavelength bands dhau los. Nws siv FBG fiber ntau optic cable gratings los yog cov ntxaij lim dej kom muaj kev cuam tshuam txog kev cuam tshuam wavelengths rov qab, thaum ib txwm dhau lwm cov kev sib txuas lus uas ...
1.Optical fiber ntau reflector yog ib qho khoom siv kho qhov muag uas tsuas tso cai rau qee qhov wavelength bands dhau los. Nws siv FBG fiber optic cable gratings los yog cov ntxaij lim dej kom muaj kev cuam tshuam cov kev cuam tshuam wavelengths rov qab, thaum ib txwm dhau lwm txoj kev sib txuas lus uas tsis nyob hauv qhov tshwj xeeb cuam tshuam wavelength ntau yam.
2.Optical fiber ntau reflectors muaj tsawg nkag poob hauv qhov sib kis wavelength ntau thiab siab reflectivity nyob rau hauv lub reflection wavelength ntau. Lawv zoo tagnrho rau FTTX network txuas saib xyuas thiab tsim nyog rau point-to-point lossis point-to-multipoint networks. Feem ntau ntsia tau rau hauv tus neeg siv lub tsev los qhia txog cov chaw no hauv OTDR kab los ntawm kev xav txog cov teeb liab kuaj.
Yam khoom | Chav tsev | SC FBG Reflector Pigtail Hom | ||
Kev ua haujlwm band | Transmission band | nm | 1260~1625 | 1260~1600 |
Reflection band | nm | 1645~1655 | 1620~1630 | |
IL | dB | Tsawg dua los yog sib npaug rau 1.4 1260~ 1360nm | Tsawg dua los yog sib npaug rau 1.4 1260~ 1360nm | |
| Tsawg dua lossis sib npaug rau 1.4 1460~ 1600nm | Tsawg dua lossis sib npaug rau 1.4 1460~ 1580nm | |||
| Tsawg dua lossis sib npaug rau 2.0 1600~ 1625nm | Tsawg dua lossis sib npaug rau 2.0 1580~ 1600nm | |||
| >21 1645 ~ 1655nm | >21 1620 ~ 1630nm | |||
RL | dB | >35 1260 ~ 1360nm | >35 1260 ~ 1360nm | |
| >35 1460 ~ 1600nm | >35 1460 ~ 1580nm | |||
| >25 1600 ~ 1625nm | >25 1580 ~ 1600nm | |||
| Tsawg dua los yog sib npaug rau 1.0 1645~ 1655nm | Tsawg dua lossis sib npaug rau 1.0 1620~ 1630nm | |||
PDL | dB | Tsawg dua lossis sib npaug rau 0.4 | ||
Ripple | dB | Tsawg dua lossis sib npaug rau 0.6 | ||
TDL | dB | Tsawg dua lossis sib npaug rau 0.5 | ||
Qhov siab tshaj plaws optical zog | dBm ib | Tsawg dua los yog sib npaug 27 | ||
Hom Ferrule | / | PC/APC | ||
Kev taw qhia kis | / | Unidirectional | ||
Hom Fiber | / | Corning G657A2 thiab 900um xoob raj | ||
Ua haujlwm kub | degree | -20~+70 | ||
Ua haujlwm av noo | %RH | 5~95 | ||
Cia kub | degree | -40~+85 | ||
1.Standard loj, ceev installation
2. Qhov kev ua haujlwm tsis zoo yog qhov ruaj khov
3. Raws li cov qauv thoob ntiaj teb: GR 326 lossis IEC 61300-2, IEC 61754-4, RoHS, UL 94-V0 thiab lwm yam qauv.
FTTX
PON
Data center
OTDR test
Central computer chav kuaj
Fiber Line saib xyuas
Data center
OTDR test
Fiber kab saib xyuas
