SC FBG Reflector Pigtail Hom
SC FBG Reflector Pigtail Hom FBG fiber ntau grating reflector yog hu ua fiber ntau Bragg grating filter, uas yog lub wavelength selective reflector. Nws feem ntau yog ntsia rau pem hauv ntej kawg ntawm ONU ntawm qhov kho qhov muag network kom ua tiav qhov tseeb thiab nrawm nrhiav pom qhov kawg-rau-kawg attenuation ntawm ...
1.Fiber (FBG) reflectors, tseem hu ua fiber ntau Bragg grating filters, feem ntau yog ntsia rau pem hauv ntej kawg ntawm optical network ONUs. Ua ke nrog OTDR cov cuab yeej, lawv tuaj yeem paub qhov point-to-point (PTP) lossis point-to-multipoint (PTMP) network saib xyuas kev sib txuas kho qhov muag. Muaj tseeb muaj kev cuam tshuam txog kev sib koom tes network;
2.End-rau-kawg OTDR kev ntsuas los ntawm OLT rau ONT feem ntau nyuaj vim kev poob siab thiab kev sib txuas ua ke uas tau qhia los ntawm cov splitters. Daim ntawv thov ntawm optical fiber reflectors yog ib qho txiaj ntsig zoo los pab OTDR nrhiav pom, thiab nws yog txoj hauv kev zoo tshaj plaws kom ua tiav lub sijhawm kawg-rau-kawg (OLT rau ONT) kev saib xyuas ntawm cov tes hauj lwm kho qhov muag hauv FTTx tes hauj lwm.
Yam khoom | Chav tsev | SC FBG Reflector Pigtail Hom | ||
Kev ua haujlwm band | Transmission band | nm | 1260~1625 | 1260~1600 |
Reflection band | nm | 1645~1655 | 1620~1630 | |
IL | dB | Tsawg dua los yog sib npaug rau 1.4 1260~ 1360nm | Tsawg dua los yog sib npaug rau 1.4 1260~ 1360nm | |
| Tsawg dua lossis sib npaug rau 1.4 1460~ 1600nm | Tsawg dua lossis sib npaug rau 1.4 1460~ 1580nm | |||
| Tsawg dua lossis sib npaug rau 2.0 1600~ 1625nm | Tsawg dua lossis sib npaug rau 2.0 1580~ 1600nm | |||
| >21 1645 ~ 1655nm | >21 1620 ~ 1630nm | |||
ORL | dB | >35 1260 ~ 1360nm | >35 1260 ~ 1360nm | |
| >35 1460 ~ 1600nm | >35 1460 ~ 1580nm | |||
| >25 1600 ~ 1625nm | >25 1580 ~ 1600nm | |||
| Tsawg dua los yog sib npaug rau 1.0 1645~ 1655nm | Tsawg dua lossis sib npaug rau 1.0 1620~ 1630nm | |||
PDL | dB | Tsawg dua lossis sib npaug rau 0.4 | ||
Ripple | dB | Tsawg dua lossis sib npaug rau 0.6 | ||
TDL | dB | Tsawg dua lossis sib npaug rau 0.5 | ||
Qhov siab tshaj plaws optical zog | dBm ib | Tsawg dua los yog sib npaug 27 | ||
Hom Ferrule | / | PC/APC | ||
Kev taw qhia kis | / | Unidirectional | ||
Hom Fiber | / | Corning G657A2 thiab 900um xoob raj | ||
Ua haujlwm kub | degree | -20~+70 | ||
Ua haujlwm av noo | %RH | 5~95 | ||
Cia kub | degree | -40~+85 | ||
1. Tsis tshua muaj qhov ntxig poob
2. High reflectivity
3. Yooj yim rau nruab
4. Kev ruaj ntseg siab thiab kev ntseeg siab
5. Ua raws li kev lees paub thoob ntiaj teb: GR326 lossis IEC 61300-2, ROHS, IEC 61754-4, UL 94-V0
1. Central computer room reflectivity test
2. Kev sib txuas lus sib txuas kom paub meej
3. OTDR test
4. PON network
5. FTTX
Central Computer Room Reflectivity Test
Kev sib txuas lus system txuas nrhiav kom tau
OTDR test
ISO9001
CE
CPR
ROHS
