LC rau LC OM2 Duplex Patch Cord Cable

OPTICO LC rau LC OM2 Muti-hom Duplex Patch Cord yog qhov zoo thiab muaj npe nrov.OPTICO LC rau LC OM2 Duplex optic fiber cable yog tsim rau ceev Ethernet, gigabit Ethernet thiab fiber ntau channel daim ntaub ntawv, xws li hauv cov ntaub ntawv chaw, chav sib tham, neeg rau zaub mov. ua liaj ua teb, huab cia network, thiab txhua qhov chaw fiber ntau jumper cables xav tau.

Xa kev nug

Ces

LC rau LC OM2 Muti-hom Duplex Patch Cord Cable

LC rau LC OM2 duplex thaj qaum nta tshwj xeeb tsim LC uniboot connectors uas tso cai rau kev sib kis ntawm cov teeb liab ntawm qhov muag hauv ib qho fiber ntau, muab ntau txoj hauv kev rau kev sib txuas siab.

Muaj ob hom ntawm fiber ntau optic cabling, singlemode thiab multimode. Cov kab ntawv teev npe ntawm no yog cov kab hluav taws xob multimode. Nyob rau hauv cov kab no koj yuav pom peb txheej txheej. Pib los ntawm sab hauv, koj muaj cov tub ntxhais nyob ib puag ncig los ntawm cladding. Ob leeg muaj kev tiv thaiv nrog lub tsho sab nrauv. Multimode cables muaj ib tug tuab "core loj". Core loj yog tsuas yog lub thickness ntawm fiber nyob rau hauv lub cladding. Lub cladding yog cov khoom uas nyob ib puag ncig ntawm lub hauv paus, qhov tseem ceeb ua tus ciam teb rau lub teeb liab, ua kom lub teeb ua kom zoo rau cov tub ntxhais thiab tsis cia nws khiav. Qhov tuab ntawm cov tub ntxhais loj, qhov ntau dua qhov teeb meem pom, qhov teeb meem ntau dua tshwm sim, thiab nkag siab qhov luv dua qhov kev ncua deb ntawm lub teeb liab tuaj yeem mus. Thaum kawg, lub tsho yog ib feem ntawm cov kab uas koj pom. Cov txheej no tiv thaiv cov cable thiab muab kev qhia yooj yim raws li nws cov xim.

Parameter	LC/SC/FC/ST/MU/MTRJ/E2000
	SM		MM
	UPC	APC	APC
Ua haujlwm wavelength (nm)	1310,1490,1550		850,1300
Insertion poob (dB)	Tsawg dua lossis sib npaug rau 0.25	Tsawg dua lossis sib npaug rau 0.20	Ntau dua lossis sib npaug li 65
Rov qab poob (dB)	Ntau dua lossis sib npaug li 55	Ntau dua lossis sib npaug li 65	Ntau dua lossis sib npaug li 55
Rov ua dua (dB)	Tsawg dua lossis sib npaug rau 0.10
Interchangeability (dB)	Tsawg dua lossis sib npaug rau 0.20
Plug Testing (lub sijhawm)	Ntau tshaj los yog sib npaug rau 1000
Tensile zog (N)	{{0}}.9mm(9N); 2. 0mm(70N); 3.0 hli (75N)
Durability (dB)	Tsawg dua lossis sib npaug rau 0.20
Ua haujlwm kub (degree)	-40~+85
Cia kub (degree)	-20~+75

Nta

• High quality CCTC ceramic ferrules

• Zoo repeatability thiab interchangeability

• Zoo meej tov rau nruab uas yuav tsum tau

• CE/CPR/ISO/ROHS√

• 100% 3D kuaj los ntawm DAISI / Kub kuaj / poob kuaj ua ntej xa khoom

• Kev ntsuas kub siab thiab qis qis

• Cov ntaub ntawv ruaj khov interchangeability

• Ntev mating voj voog

IL&RL Test

3D Test

End-face Test.jpg

End-face Test

Cov ntawv thov

Data Center

FTTH

Cov ntawv pov thawj

test report1.jpg

CTI: ntsuas kub

CTI: poob test

test report 3.jpg

CTI: durability test

CTI: ntsuas kub thiab av noo

test report 5.jpg

CTI: ntsuas kub

test report 6.jpg

CTI: poob test

test report 7.jpg

CTI: resistant rau dabtsi yog khoov

test report 8.jpg

CTI: sine vibration test

Daim ntawv pov thawj kev lag luam high-tech yog daim ntawv pov thawj hauv teb chaws uas tau muab los ntawm Shenzhen rau peb lub tuam txhab, uas txhais tau hais tias lub tuam txhab muaj peev xwm muaj peev xwm thev naus laus zis tshiab thiab kev tsim kho thev naus laus zis muaj peev xwm hauv kev sib txuas lus kho qhov muag.
