SC rau SC OM5 Patch Cable
OPTICO SC rau SC OM5 Muti-hom Patch Cord yog qhov zoo thiab muaj npe nrov.OPTICO SC rau SC OM5 optic fiber ntau cable yog tsim rau ceev Ethernet, gigabit Ethernet thiab fiber ntau channel daim ntaub ntawv, xws li nyob rau hauv cov ntaub ntawv chaw, chav telecom, server teb, huab cia tes hauj lwm, thiab txhua qhov chaw fiber ntau jumper cables xav tau.
1.SC rau SC OM5 thaj qaum yog booming xyoo no. Xav txog tus nqi ntawm cov cabling, kev xa tawm ntawm ib hom fiber ntau hauv cov chaw khaws ntaub ntawv tseem txwv. Piv nrog rau ib hom fiber ntau, OM5 txhawb nqa plaub tus nqi qis qis, uas tuaj yeem nce cov ntaub ntawv muaj peev xwm los ntawm 4 zaug thaum txo cov fibers; Tsis tas li ntawd, ntau hom fiber ntau muaj qhov zoo dua hauv kev teeb tsa, kev daws teeb meem, tu thiab tu, thiab lwm yam, thiab vim li no, OM5 multimode fiber ntau yog qhov kev xaiv zoo rau cov ntaub ntawv chaw.
2.Fiber thaj cords yog siv los ua thaj cords los ntawm cov khoom siv rau fiber ntau optic cable txuas. Muaj cov txheej tiv thaiv tuab dua, thiab cov khoom sib txuas nquag tau nruab rau ntawm ob qho kawg kom paub txog kev sib txuas ntawm txoj kev kho qhov muag. Nrog rau kev txhim kho txuas ntxiv ntawm cov kev xav tau sib kis, OM5 fiber ntau optic thaj qaum tau pib siv ntau thiab ntau dua.
Thaum pib, OM5 fiber ntau thaj qaum yog hu ua broadband multimode fiber ntau thaj qaum (WBMMF), uas yog tus qauv tshiab rau fiber ntau thaj qaum txhais los ntawm TIA thiab IEC. Thiab tuaj yeem txhawb 4 wavelengths.
Hais txog cov qauv, nws tsis txawv ntawm OM3 thiab OM4 fiber ntau thaj cords, yog li nws yog tag nrho rov qab sib xws nrog cov tsoos OM3 thiab OM4 multimode fiber ntau thaj qaum.
| Parameter | LC/SC/FC/ST/MU/MTRJ/E2000 | ||
| SM | MM | ||
| UPC | APC | APC | |
| Ua haujlwm wavelength (nm) | 1310,1490,1550 | 850,1300 | |
| Insertion poob (dB) | Tsawg dua lossis sib npaug rau 0.25 | Tsawg dua lossis sib npaug rau 0.20 | Ntau dua lossis sib npaug li 65 |
| Rov qab poob (dB) | Ntau dua lossis sib npaug li 55 | Ntau dua lossis sib npaug li 65 | Ntau dua lossis sib npaug li 55 |
| Rov ua dua (dB) | Tsawg dua lossis sib npaug rau 0.10 | ||
| Interchangeability (dB) | Tsawg dua lossis sib npaug rau 0.20 | ||
| Plug Testing (lub sijhawm) | Ntau tshaj los yog sib npaug rau 1000 | ||
| Tensile zog (N) | {{0}}.9mm(9N); 2. 0mm(70N); 3.0 hli (75N) | ||
| Durability (dB) | Tsawg dua lossis sib npaug rau 0.20 | ||
| Ua haujlwm kub (degree) | -40~+85 | ||
| Cia kub (degree) | -20~+75 | ||
• High quality CCTC ceramic ferrules
• Zoo repeatability thiab interchangeability
• Zoo meej tov rau nruab uas yuav tsum tau
• CE/CPR/ISO/ROHS√
• 100% 3D kuaj / Kub ntsuas / poob kuaj ua ntej xa khoom
• Kev ntsuas kub siab thiab qis qis
• Cov ntaub ntawv ruaj khov interchangeability
• Ntev mating voj voog
IL&RL Test
3D Test
End-face Test
Data Center
FTTH
FTTH
