1x2 ABS PLC Splitter
1x2 ABS PLC Splitter yog ib yam khoom siv hluav taws xob sib koom ua ke tsim los ntawm kev siv cov cuab yeej kho qhov muag kho qhov muag los ntawm cov khoom siv quartz substrate.
1x2 ABS PLC Splitter --- Thaum lub teeb liab kho qhov muag tau xa mus rau hauv ib hom fiber ntau, lub teeb lub zog tsis tuaj yeem ua kom muaj zog hauv cov tub ntxhais kom nthuav tawm, thiab me me ntawm lub teeb lub zog yog propagated nyob ze ntawm fiber ntau cladding. Feem ntau, thaum lub cores ntawm ob optical fibers nyob ze txaus, lub optical teeb liab kis tau nyob rau hauv ib tug optical fiber yuav nkag mus rau lwm yam optical fiber, uas yog, lub optical teeb liab yuav tsum redistributed nyob rau hauv ob optical fibers, uas yog raws nraim lub hauv paus chiv keeb ntawm. optical splitter.
Cov hom kev sib txuas thiab cov ntim ntim ntawm 1x2 ABS PLC Splitter tuaj yeem kho raws li cov neeg siv khoom xav tau.
Txais tos tuaj xyuas peb lub Hoobkas VR:
OPTICO Fiber Assemblies Ntau Lawm Kab VR:https://www.linked-reality.com/company/15555/en
| Parameter | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 1x128 | |
| Ua haujlwm wavelength (nm) | 1260~1650 | |||||||
| Hom Fiber | G657A los yog customized | |||||||
| Hom Insertion Loss (dB) | 4.0 | 7.0 | 10.0 | 13.2 | 16.5 | 20.5 | 24.5 | |
| Loss Uniformity (Max.) | 0.5 | 0.5 | 1.0 | 1.4 | 1.6 | 2.0 | 2.6 | |
| PDL (Max.) | 0.2 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 | 0.8 | |
| Rov Los Loss (dB) | Ntau dua lossis sib npaug li 55 | |||||||
| Kev taw qhia (dB) | Ntau dua lossis sib npaug li 55 | |||||||
| Wavelength nyob ntawm qhov poob (dB) | Tsawg dua lossis sib npaug rau 0.3 | |||||||
| Ua haujlwm kub (degree) | -40~+85 | |||||||
| Qhov Loj (mm) | ABS Box | 100x80x10 | 100x80x10 | 100x80x10 | 120x80x10 | 140x115x18 | 140x115x18 | |
• Kev poob qis qis thiab rov qab poob siab
• PDL tsis siv neeg tshuaj ntsuam xyuas (Ultra low PDL yog muaj)
• Muaj kev ntseeg siab thiab ruaj khov
• Connector tuaj yeem mus txog qib B
• 100% 3D kuaj los ntawm Daisi thiab Sumix
• Kev ntsuas ntsuas kub-tsawg kub
• 100% kuaj ua ntej xa khoom
• FTTH Cable Solution tuaj yeem tsim
Xaus ntsej muag Test
IL&RL Test
3D Test
Fiber rau Qhov Point (FTTX)
Fiber rau Lub Tsev (FTTH)
Passive Optical Networks (PON)
Gigabit Passive Optical Networks (GPON)
Local Area Networks (LAN)
Cable TV (CATV)
Cov khoom siv kuaj
FTTH
CATV
ISO
CE
ROHS
CPR
