ST / UPC OM5 Duplex Patch Cord
OPTICO ST-ST UPC thaj qaum optic fiber ntau cable yog tsim rau ceev Ethernet, gigabit Ethernet thiab fiber ntau channel daim ntaub ntawv, xws li nyob rau hauv cov ntaub ntawv chaw, telecom chav, neeg rau zaub mov ua liaj ua teb, huab cia network, thiab txhua qhov chaw fiber ntau jumper cables xav tau.
ST/UPC OM5 Duplex FTTH Optic Fiber Jumper
Fiber thaj cables tuaj yeem siv nrog ntau lub network, xws li optical transceiver modules, fiber ntau adapter panels, fiber ntau cassettes, media converters, thiab lwm yam khoom uas muaj fiber ntau optic interfaces.
OPTICO's ST/UPC rau ST/UPC duplex multi-mode fiber ntau thaj qaum muaj Insertion poob qis dua 0.25dB thiab Rov Los Poob siab dua 35dB. Xws li kev ua haujlwm siab pab peb cov khoom lag luam tau nrov dua ntawm ntau lub tebchaws nyob sab Europe. Cov kev xav tau qis heev tuaj yeem ua tiav.
| Hom Connector | ST/UPC rau ST/UPC | Fiber suav | Duplex |
| Ua haujlwm Wavelength | 850/1300 nm | Fiber hom | MM 50 / 125μm OM5 |
| Insertion Loss (IL) | Tsawg dua lossis sib npaug rau 0.25dB | Cable Xim | Txiv qaub ntsuab |
| Rov Los Loss (RL) | Ntau dua lossis sib npaug li 35dB | Hloov pauv tau | Tsawg dua lossis sib npaug rau 0.20dB |
| Rov ua dua | Tsawg dua los yog sib npaug rau 0.10dB | Plug Test | Ntau dua lossis sib npaug li 1000 npaug |
| Tensile zog | Ntau dua lossis sib npaug rau 100N | Durability | Tsawg dua lossis sib npaug rau 0.20dB |
| Kev khiav haujlwmKub | -40 ~ +85 degree | Cia Kub | -40 ~ +85 degree |
• Fiber hom: MM 50/125μm OM5, lub tsho txiv kab ntxwv xim
• Cable txoj kab uas hla: 2.0mm los yog kev cai
• Min. Khoov Radius ntawm 7.5mm
• High quality CCTC ceramic ferrules
• Ntev mating voj voog, kev ua haujlwm ruaj khov
• Kev ua haujlwm ib puag ncig -40~+85 degree (-40~+185℉)
• Kev soj ntsuam nruj me ntsis ntawm 3D, kub thiab poob nrog cov tshuab ntsuas automated
• Kev sib txuas lus hauv xov tooj;
• Cov cuab yeej siv tau txiav tawm;
• Kev sib txuas hauv cheeb tsam (LAN);
• Cov ntaub ntawv ua cov tes hauj lwm;
• Cov khoom siv kuaj;
• Wide area networks (WAN);
• FTTX, FTTH
Cim npe nrov: st/upc om5 duplex thaj qaum, Tuam Tshoj st/upc om5 duplex thaj qaum manufacturers, lwm tus neeg, Hoobkas
