2 x 2 Singlemode Dual Window FBT Coupler

2x2 Multimode Dual Window FBT Coupler Rau FBT Splitters, Optico muab tag nrho cov hom no kho rau cov ntawv thov tshwj xeeb: a. Kev sib txawv ntawm qhov sib txawv ntawm lub zog kho qhov muag tuaj yeem xaiv tau: 40/60, 30/70, 20/80, 10/90, 5/95, 2/98, 1/99 ... b. Ob ntawm 1310nm, 1490nm thiab 1550nm ...

Xa kev nug

Ces

2x2 Ib hom Dual Qhov rai FBT Coupler

Rau FBT Splitters, Optico muab tag nrho cov kab no kho kom haum rau cov ntawv thov tshwj xeeb:

a. Qhov sib txawv ntawm qhov sib txawv ntawm lub zog kho qhov muag tuaj yeem xaiv tau: 40/60, 30/70, 20/80, 10/90, 5/95, 2/98, 1/99 ...

b. Ob ntawm 1310nm, 1490nm thiab 1550nm kev khiav haujlwm wavelength tuaj yeem xaiv.

c.1x2, 1x3, 1x4, 2x2, 2x4, 3x3 configurations ntawm splitters muaj.

d. 250um liab qab fiber ntau, 0.9 xoob raj, 2. 0mm lossis 3.0mm LSZH fiber ntau cables tuaj yeem xaiv.

e. Qhov ntev ntawm cov tswv yim lossis cov zis fibers tuaj yeem kho tau.

Txais tos tiv tauj peb rau kev daws teeb meem.

Parameter	2x2
Connector hom thiab fiber ntev	Customized
Hom Fiber	OM1/OM2/OM3/OM4/OM5
Pob Loj	250um liab qab fiber ntau	Φ3 0mmx40mm
	250um liab qab fiber ntau	Φ3 0mmx54mm
	900um cev	Φ3 0mmx54mm
	900um/2.0mm/.0 3mm cev	L90xW20xH10mm
Ua haujlwm wavelength	850 lossis 1310, lwm yam raws li kev cai
Ua haujlwm bandwidth	±40
Feem ntau poob	Tsawg dua lossis sib npaug rau 0.4
Insertion poob	50/50	Tsawg dua lossis sib npaug li 3.7 / 3.7
	40/60	Tsawg dua lossis sib npaug li 4.7 / 2.7
	30/70	Tsawg dua lossis sib npaug rau 6.0/2.1
	20/80	Tsawg dua lossis sib npaug li 7.8 / 1.4
	10/90	Tsawg dua los yog sib npaug rau 11.2/0.9
	5/95	Tsawg dua los yog sib npaug rau 14.5/0.7
	2/98	Tsawg dua lossis sib npaug rau 18.6/0.6
Kev tsis sib xws	Tsawg dua lossis sib npaug rau 0.5
Kev taw qhia	Ntau dua lossis sib npaug li 40
Ua haujlwm kub	-40 ~ +85 degree
